Ametek Lamb 2-Stage Tangential Bypass Vacuum Motor - 5.7 Inch Diameter

Ametek Lamb 2-Stage Tangential Bypass Vacuum Motor - 5.7 Inch Diameter

$229.99 USD
$229.99 USD
Sale Sold out
Shipping calculated at checkout.

122685-00
Free Shipping On Orders $100+
Expert Support 35+ Years Experience
Easy Returns 35-Day Policy

Shipping Information

We offer FREE shipping on orders of $100 or more within the continental United States.

Orders typically ship out from our store within 1-5 business days, and most orders arrive 2-11 business days after they are placed. Special order items may require additional processing time.

Returns & Exchanges

We offer a 35-day return policy on all unused items in original packaging. A Return Authorization (RA#) is required.

To initiate a return, please contact our customer service team. Return shipping costs may apply for non-defective items.

Warranty Information

All products sold by Vacuums and More come with the manufacturer's warranty. Warranty terms vary by brand and product.

With 35 years of industry experience, we stand behind every product we sell. Contact us for warranty support.

View full details

Ametek Lamb 2-Stage Tangent...

$229.99

Product details

This is an Ametek Lamb two-stage tangential bypass vacuum motor, part 122685-00, built on a 5.7 in. fan case with a tangential discharge outlet and running on 120 V AC/DC at 50-60 Hz. Published figures for this motor are 1,900 W input, 130 in. water lift, 128 CFM and 574 air watts at 15.2 amps, with a housing 7-1/2 in. tall on a 3 in. bolt spacing.

This motor is listed for the S44 and A525H, and it cross-references to earlier Lamb numbers 119914, 119956 and 119992, including 119992-01, so it can replace any of those directly. Central vacuum and portable extraction systems built by AirMaster, ModernDay, SilentMaster, Flo-Master, Beam, Vacuflo, Hayden, Honeywell and Imperium have used this motor, and a matching brush kit is stocked separately as part 833513-50.

  • Part: 122685-00
  • Configuration: two-stage, tangential bypass
  • Frame: 5.7 in. diameter, 7-1/2 in. tall, 3 in. bolt height
  • Electrical: 120 V AC/DC, 50-60 Hz, 1,900 W, 15.2 A
  • Performance: 130 in. water lift, 128 CFM, 574 air watts
  • Cross-reference: 119914, 119956, 119992, 119992-01

When a motor loses suction, throws heavy sparking at the brush contacts, or simply stops running after years on the job, that combination points to the motor itself rather than something downstream, and a straight swap is the fix. Confirm the fan case diameter and mounting bolt spacing against your old motor before ordering.

Verified against: Ametek Lamb model data for 122685-00
