SEBO Rear Bottom Plate for ...
$14.00
Product details
Rear plates are model-specific on these mechanical uprights, so order by the badge on the machine rather than by how the panel looks. Part 50310HGER is the light gray plate specified for the SEBO 300 Mechanical, and SEBO records it at position 116 of the parts diagram as the rear bottom plate 300.
The plate closes the back of the nozzle underside and sets how the trailing edge meets the carpet. Worn thin against grit or cracked at a fixing point, it stops holding that edge down, the base begins to rock on the stroke, and pickup goes patchy behind the brush roll. The wear is gradual rather than dramatic, which is why it is usually found during a brush roll service rather than reported as a fault. A new plate restores both the seal and the ride height the nozzle was designed around.
The underside is worth doing as one job. The matching front panel for this machine is 50404HGER, brush roller release 50403HGER and brush roller mechanism 50470ER sit in the same head, and brush roller strip 50415 is the wear item that fits it. Bearing blocks 50355HG on the left and 50356HG on the right carry the roll, brush strip cover 50352HG closes over it, and belts 5110 and 5379 drive it. Chassis 50414HGER and power head cover 50401GSAM complete the model-specific list.
- Part number: 50310HGER
- Fits: SEBO 300 Mechanical
- Finish: light gray
- Diagram position: 116, listed as rear bottom plate 300
- Job: seals and levels the rear of the nozzle underside
- Check it: whenever the machine is tipped over for a brush roll service
- Related part numbers: 50404HGER front bottom plate, 50403HGER brush roller release, 50415 brush roller strip, 50355HG and 50356HG bearing blocks
Genuine SEBO stock through an authorized dealer, and the correct answer for a SEBO 300 Mechanical rear sole plate or bottom plate replacement. Ships in 2-5 business days.
