SEBO Screw C 2.9 x 9.5 (DIN...
$6.99
Product details
Ten identical 2.9 x 9.5 mm C-point screws come bagged together under 0100ER, so a full teardown of an AUTOMATIC X upright can go back together without hunting for a replacement halfway through the job.
Repair benches work through these far faster than owners do. Every removal and refit takes a little more material out of the plastic boss the screw cuts into, and after several services the same fastener no longer pulls down cleanly. It feels tight for a moment and then spins. Working from a bag of ten means each hole gets an unworn screw rather than the one that felt slightly soft going in, and it removes the temptation to force a stripped fixing that will only have to be drilled out later.
The specification is unchanged from the single-piece listing: a cross-recessed pan head tapping screw to DIN 7981 with a cone point, 2.9 mm diameter and 9.5 mm long, appearing at item 130 on SEBO's AUTOMATIC X4/X5 parts diagram. It is the short screw of the X series housing, used where the panel being fixed is thin and a longer shank would push through the moulding behind it. Anyone servicing more than one machine, or expecting to open the same one again, is better served by the bag than by ordering singles twice.
- Fits: SEBO AUTOMATIC X1, AUTOMATIC X2, AUTOMATIC X4, AUTOMATIC X4 Boost and AUTOMATIC X5
- Size: 2.9 x 9.5 mm, DIN 7981 C point
- Quantity: 10 screws, part 0100ER
- Single screw: part 0100
- Diagram position: item 130, AUTOMATIC X4/X5 sheet
- Related hardware: locking washer 0141ER, washer 0143ER
Count them out before starting rather than at the end. Ten in the bag turns a screw that disappears under the bench into a two-second inconvenience instead of a rebuild that stops where it stands, and it leaves a few spares in the drawer for the next time the same panel comes off.
Genuine SEBO hardware supplied by an authorized dealer. Ships in 2–5 business days.
