SEBO Printed Circuit Board, 120 Volt, for SOFTCASE CE12

Voltage matters on this one. 75126ER is the printed circuit board SEBO specifies for the 120 volt build of the SOFTCASE CE12, listed at position 120 on the machine's parts sheet as PCB 120 V. Machines built for other supply voltages take a different board, so confirm which version is on the bench before ordering.

Boards come out for a small number of reasons and none of them are routine. A surge on the supply, moisture or liquid finding its way inside the body, or a fault that a technician has already chased past the cord, the switching and the cable and can only account for at the electronics. Replacing a board on a hunch is expensive guesswork; replacing one after the rest of the circuit has been proved sound is a repair.

The CE12 diagram makes that process straightforward because the electrical group is drawn in sequence. The mains cable is position 15 and the mains connector position 10, the two-wire swivel neck cable is 113, the board itself 120, the motor bridge 122, the torque sensor 124 and the rocker switch 140. Work from the plug inwards and the board is the last suspect rather than the first.

• Part number: 75126ER
• Rating: 120 V, the board SEBO lists for this build
• Fits: SEBO SOFTCASE CE12 upright vacuum
• Diagram position: 120 on the SOFTCASE CE12 parts list
• Supplied: one board, genuine SEBO electronics
• Adjacent positions: motor bridge at 122, torque sensor at 124

Handle the board by its edges and keep it dry until it is in place.

Only fit the board with the machine disconnected. Typical searches are SEBO PCB 120V, CE12 circuit board and SOFTCASE CE12 control board. Ships in 2-5 business days.
