SEBO Brush Roll Sensor Asse...
$44.00
Product details
SEBO's automatic control on the AUTOMATIC X8 leans on a small sensor at the brush roll to know whether the roller is actually turning. When that reading drifts, the machine can raise a fault or cut the drive even though the roller and belt are in good order. Part 52198 replaces the whole assembly, pulley and fixing screws included.
SEBO records it at position 134 in the combined AUTOMATIC X7/X8 parts diagram, catalogued specifically as the complete X8 sensor. More than one assembly is listed at that position across the sheet, so the part number is what settles it rather than the drawing. Fitting the complete unit instead of a bare sensor keeps the pulley matched to the new sensor, which is what keeps the reading honest.
The reason it can sense anything is its place in the belt run. Belt 5463 arrives from the motor pulley and drives the sensor; belt 5110 leaves the sensor and drives the bearing block carrying the brush roll. A stalled roller, a stretched belt or a pulley worn smooth all change the relationship between those two, and the sensor is the part reporting it. That also means a fault here is worth diagnosing alongside the belts and the left-hand bearing block 52121 rather than in isolation.
- Fits: SEBO AUTOMATIC X8
- Part number: 52198
- Supplied as: complete sensor assembly with pulley and mounting screws
- Diagram position: 134 on the combined AUTOMATIC X7/X8 sheet
- Drive-train neighbours: belt 5463 from the motor, belt 5110 to the bearing block, bearing block 52121, motor pulley 5462
Photograph how the belts sit on the pulleys before you take the old unit out, and turn the roller by hand afterwards to confirm nothing binds. Genuine SEBO part supplied by an authorized dealer. Ships in 2–5 business days.
