Canplas Spigot Coupling - C...
$6.99
Product details
This Canplas spigot coupling joins two sections of central vacuum tubing end to end, the fitting installers reach for constantly throughout a piping network wherever a run needs to be extended, repaired, or tied into an existing system.
A coupling that seats and cements correctly holds suction steady from the power unit clear out to the inlet farthest down the line, while one that is rushed or misaligned lets performance bleed away throughout the house without any single obvious failure point. That is why installers are particular about matching the coupling to the pipe rather than forcing a loose fit and relying on extra cement to close the gap.
This coupling fits standard central vacuum tubing on both ends. Confirm the pipe seats fully with a dry pass before committing, then solvent-weld per your installation guidelines for a permanent, airtight seal. It is inexpensive enough that keeping a few spares on hand speeds up any tubing project.
Rotate the pipe slightly while pressing it into the coupling during dry-fit, since this helps distribute cement evenly around the joint once you commit to the permanent connection. Wipe away excess cement from the outside of the joint before it sets, since dried cement on the exterior can interfere with a collar or bracket installed nearby later.
- Part: 765527W, Canplas spigot coupling
- Fits: standard central vacuum tubing runs
- Use: joins two pipe sections end to end during extension or repair
- Install: dry-fit, then solvent-weld both ends for an airtight seal
