Hayden SuperValve III Full-...
$26.99
Product details
The Hayden SuperValve III, part 792090W in white, is a full-door electric wall inlet listed for the Hayden 0627 central vacuum system. Electric inlets carry a built-in power connection behind the door, so a corded power head plugged into the hose cuff draws its electricity from the inlet itself rather than a wall outlet across the room.
A full-door design covers the entire opening rather than a narrow slot, which keeps the inlet's inner cavity cleaner between uses and gives the door enough surface area to close flush against the wall plate when nothing is plugged in. Because the door swings on a hinge, it also holds the hose cuff at the right angle while a hose is connected, instead of relying on the hose's own weight to keep the valve seated.
Full-door electric inlets like this one are usually placed at the inlet used most in a home, a family room or main hallway, since the door mechanism sees more open-and-close cycles there than at an occasional-use inlet in a bedroom closet. A gasket around the door frame is what keeps the seal airtight when closed, and a gasket that has hardened or compressed over years of use is a common source of a faint air leak at that one inlet even when the rest of the system checks out fine.
- Part: Hayden 792090W, SuperValve III electric inlet, white
- Fits: Hayden 0627 central vacuum systems
- Function: full-door electric inlet with built-in power connection for a corded power head
- Install note: needs a power run to the valve location in addition to the vacuum pipe
Electric inlets need a power run to the valve location in addition to the standard 2-inch pipe stub, so plan the wiring path at rough-in rather than trying to fish it in afterward. Confirm the inlet is listed for the Hayden 0627 before ordering if you are matching an existing system rather than starting new.
