SEBO Top Casing with Bag Spring for AIRBELT D1 Turbo - Black Cherry

Hinges go oval, springs slacken, and the bag compartment on an older canister stops shutting as it should. This black cherry upper shell for the AIRBELT D1 Turbo covers all three, because SEBO supplies it as a kit and not as a bare casing. Part number 8003SRER.

Three service items travel with the casing. The filter bag spring is 8140ER, drawn at position 23 on the AIRBELT D diagram, and it is what holds the bag collar pressed against its port so dust cannot bypass the bag. The cover axle set is 6750ER at position 24, and the pair of cover hinges with their axles is 8052ER. Those small components tend to fail around the same time a casing cracks, which is why SEBO groups them.

Once fitted, the compartment closes on a true axis again and the bag is held firmly on its seal. While the machine is open, the parts that share the compartment are worth a look: the bag cover seal is 8130 at position 34, the bag indicator adjuster is 8127ER at 33 with the indicator itself listed as 7020ER, and the complete inside bag cover for this model is 8051AM1. The matching black cherry outer cover is 8005SRER, and bags are 8120AM in boxes of eight.

• Machine fitment: SEBO AIRBELT D1 Turbo canister
• Black cherry finish; white version of the same casing is 8003WEER
• Bag spring 8140ER in the kit
• Cover axle set 6750ER and hinge pair with axles 8052ER included
• Matching bag cover 8005SRER, bag cover seal 8130
• Genuine SEBO part, ordered as 8003SRER

New stock from an authorized SEBO dealer, shipping in 2-5 business days.

Color counts as much as model on this panel, since the casing forms the visible upper half of the canister. Black cherry pairs with the lower shell 8001SRER and the outer cover 8005SRER in the same finish. Searches for an AIRBELT D1 top casing, a SEBO bag compartment housing or a D1 bag spring replacement all point here.
