SEBO Ribbon Cable for AUTOMATIC X1, X2, X4 and X5 - 2 Pack, Both Lengths

Two ribbon cables arrive in part 5205/1, one cut to the original length and one to the later revised length, so the correct cable is in the box whichever build of the machine is on the bench. That is the whole reason SEBO packs this item as a pair rather than making you identify the revision before ordering.

The cable is the link running from the power supply across to the computer controller board. Ribbon conductors fracture where they have been folded and lose contact at the header after repeated servicing, and once that happens the controller can no longer read the supply cleanly. The symptoms are electrical and intermittent: a vacuum that runs and then stops, a dead indicator panel, or a machine that refuses to start until the housing is squeezed. SEBO's exploded view for the AUTOMATIC X4 X5 shows the cable at position 113.

• Part number: 5205/1
• Fits: SEBO AUTOMATIC X1, AUTOMATIC X2, AUTOMATIC X4, AUTOMATIC X4 Boost and AUTOMATIC X5
• Quantity: two cables, original and revised lengths
• Runs between: power supply and computer controller
• Diagram position: 113 on the AUTOMATIC X4 X5 sheet
• Related part number: 5850ER power supply and computer controller kit

Measure the cable you remove and fit the matching one rather than stretching a short cable to reach. Unplug the vacuum before opening the housing, seat each end fully into its header until the latch closes, and avoid creasing the new ribbon anywhere along its run, because a sharp fold is exactly what finished the old one.

Searches for an AUTOMATIC X4 ribbon cable, an X5 controller ribbon, a SEBO power supply to controller cable, or part 5205/1 all land here. Genuine SEBO, shipped in 2-5 business days.
