Ametek Windjammer 24 Volt Brushless DC Blower Motor - Single Stage

Ametek Windjammer 24 Volt Brushless DC Blower Motor - Single Stage

$698.99 USD
$698.99 USD
Sale Sold out
Shipping calculated at checkout.

150908-50
Free Shipping On Orders $100+
Expert Support 35+ Years Experience
Easy Returns 35-Day Policy

Shipping Information

We offer FREE shipping on orders of $100 or more within the continental United States.

Orders typically ship out from our store within 1-5 business days, and most orders arrive 2-11 business days after they are placed. Special order items may require additional processing time.

Returns & Exchanges

We offer a 35-day return policy on all unused items in original packaging. A Return Authorization (RA#) is required.

To initiate a return, please contact our customer service team. Return shipping costs may apply for non-defective items.

Warranty Information

All products sold by Vacuums and More come with the manufacturer's warranty. Warranty terms vary by brand and product.

With 35 years of industry experience, we stand behind every product we sell. Contact us for warranty support.

View full details

Ametek Windjammer 24 Volt B...

$698.99

Product details

This single-stage Windjammer blower from Ametek pairs a brushless DC design with a compact 3-inch frame, so there are no carbon brushes to wear out and no scheduled brush replacements to plan around. Running on 24 volts DC (it accepts anywhere from 16 to 28 VDC), it produces sealed pressure up to 50 inches of water with a tangential air outlet, which makes it a strong choice for medical equipment, material handling systems, and industrial air-moving builds. Speed is adjustable electrically using a 0-4 VDC analog or PWM signal from your own controller, and the low-noise fan and housing keep operation quiet. RoHS compliant. Part #150908-50.

Key specifications:

  • Motor type: Brushless DC (BLDC), single fan stage
  • Voltage: 24 VDC nominal (16-28 VDC input range)
  • Output: Tangential, high-flow class
  • Maximum sealed pressure: 50 in. H2O
