• SEBO Complete Power Head Cover in Dark Blue for AUTOMATIC X4
1 1

SEBO

SEBO Complete Power Head Cover in Dark Blue for AUTOMATIC X4

SEBO Complete Power Head Cover in Dark Blue for AUTOMATIC X4

$41.00 USD
$41.00 USD
Sale Sold out
Shipping calculated at checkout.

5786AM
Authorized Sebo Dealer Factory warranty, extended free where we can
Free Shipping On Orders $100+
Secure Checkout SSL Encrypted

Shipping Information

We offer FREE shipping on orders of $100 or more within the continental United States.

Orders typically ship out from our store within 1-5 business days, and most orders arrive 2-11 business days after they are placed. Special order items may require additional processing time.

Returns & Exchanges

We offer a 35-day return policy on all unused items in original packaging. A Return Authorization (RA#) is required.

To initiate a return, please contact our customer service team. Return shipping costs may apply for non-defective items.

Warranty Information

All products sold by Vacuums and More come with the manufacturer's warranty. Warranty terms vary by brand and product.

With 35 years of industry experience, we stand behind every product we sell. Contact us for warranty support.

View full details

SEBO Complete Power Head Co...

$41.00

Product details

SEBO 5786AM is the dark blue power head cover for the AUTOMATIC X4, and the drawing marks it item 100 with a note that the assembly takes items 101 to 103 with it. Read against the same sheet, that run covers the exhaust filter catch, the recess it works in, and the exhaust filter cover — pieces catalogued on their own in this finish as 5712DB and 5711DB. In other words the shell and the exhaust bay it forms arrive together as one moulded assembly rather than as a bare top panel.

The head runs lower than any other part of the machine, so it takes the impacts. Fractures start from a mounting boss, where the wall section is at its thinnest, and travel outward until the chamber is no longer held closed and the trim around it stops lying flat. By then two things have gone: the rigidity that holds the roller true between its bearings, and the seat the rear exhaust panel latches onto. That combination is why a broken cover repays replacing rather than taping, since neither problem stays put once the head has started to flex.

  • Machine: SEBO AUTOMATIC X4
  • Finish: dark blue
  • Sold as: complete, taking items 101 to 103 with it
  • Position on the drawing: item 100
  • Order number: 5786AM
  • Included in this finish: 5712DB exhaust filter catch, 5711DB exhaust filter cover
  • Exhaust filter for the range: 5143
  • Beneath the shell: 5010AM brush roller, 5031DB1 right-hand bearing block in dark blue, belts 5463 and 5110
  • Dark blue parts elsewhere: 5749SE front cover, 5755DB bag housing, 5713DB brush roller release, 5707DB latch release cover, 5702DB bag housing bumper base, 5768DB cable hook kit, 5721DB carrying handle

Pull the plug and wait for the roller to stop before opening anything. Since the exhaust group travels with this cover, it is also the right moment to judge the filter media rather than closing the machine up and coming back to it a fortnight later. Buyers find this listing through the number by itself, a dark blue SEBO power head cover for an X4, and a genuine SEBO cleaning head shell. Ships in 2–5 business days.
