SEBO Cord Hook for FELIX Pr...
$10.00
Product details
The mains lead on a SEBO FELIX Premium is stored by winding it in a figure of eight between two hooks on the handle tube, and part 7027SW is the black moulding that forms one of them. SEBO catalogues it at item 15 of the FELIX exploded diagram, described there as the cable hook in black.
Mechanically it is a trivial part and structurally it is not. Each hook carries the full tension of a wound cord plus the yank it gets when somebody unhooks the lead in a hurry, and all of that load lands on one moulded stem. The stem is what breaks, usually at its root, and usually the upper hook goes first because that is the one people pull against. A machine with a single hook left still cleans perfectly well, so the repair gets postponed and the lead ends up looped loosely over the handle instead. From there it slides off, gets walked on, and works its outer sheath loose near the strain relief, which is a considerably worse problem than the one it started as.
- Part number: 7027SW
- Fitment: SEBO FELIX Premium
- Shade: black, the finish SEBO uses on its Onyx-trim bodies
- Diagram position: item 15, FELIX sheet, cable hook black
- Mounts to: the handle tube, part 7081ER at item 11
- Same hook in other finishes: 7027WE white, 7027GS gray black, 7027DR red, 7027DB dark blue
If you are putting an Onyx machine back to matching trim, the parts drawn around this one on the same sheet are the black hose duct 7090SW at item 14, the bag housing cover 7093SW at item 16, the filter cover 7091SW at item 17, the lower housing 7173SE at item 19, the complete black handle 7164GSSW at item 21, the switch assembly 7038SW at item 23 and the handle release button 7082SW at item 25. Fitting both hooks in one go is worth the few extra minutes, since the survivor has taken exactly the same number of cycles as the one that let go. Made by SEBO, held by an authorized dealership, and away in 2-5 business days.
