SEBO Swivel Neck Wiring for ET-1, ET-2 and DISCO Power Heads

Of all the wiring inside a power head, the run through the swivel neck is the one that actually moves. It twists and flexes with every turn of the head and every change of direction, and part 0876ER is the pre-made loom SEBO supplies for exactly that section.

Flex fatigue is gradual and then sudden. Strands break one at a time inside insulation that still looks perfect, so the brush roll starts cutting out at a particular angle of the handle, comes back when the head is straightened, and eventually stops for good. Fits the ET-1 and ET-2 power heads in both switched and unswitched builds, the DISCO Floor Polisher, and the machines these heads are supplied on: FELIX Premium, FELIX 2 Premium, DART, AIRBELT D4 PREMIUM, AIRBELT E3 Premium, AIRBELT K3 PREMIUM and the C3.1.

• Part number: SEBO 0876ER, swivel neck wiring
• Diagram position: 114 on the SEBO ET 1 / ET 2, DART and FELIX sheets
• Typical fault: the roller drops out as the head is steered, then returns when it is straightened
• Supplied: made up to length with its terminations already fitted
• Related power head wiring: 0880 for the safety switch with its lead, 0881 for the board-to-switch harness
• Machines these heads ship on: FELIX Premium, FELIX 2 Premium, DART, AIRBELT D4 PREMIUM, AIRBELT E3 Premium, AIRBELT K3 PREMIUM and C3.1

Work the new loom through the neck's full range of movement before the housing goes back together, so nothing is trapped, stretched or pinched at the extremes of travel. Repeating the original routing matters more here than anywhere else in the machine, because this is the one length of wire that will be bent several thousand times a year.

Genuine SEBO swivel neck wiring for ET-1 and ET-2 power heads, ships in 2–5 business days.
